Siemens F114357 Fuel Injector 44 lb/hr EV6/USCAR – SET OF 8

Description

Siemens Fuel Injector 44 lb/hr EV6/USCAR – SET OF 8

Siemens Deka High Impedance (Long Style) with EV6/USCAR Connector – 44 lb./hr. 460cc

Specifications:

• Genuine, reliable Siemens Injectors
• Excellent response characteristics
• Robust Design
• High Impedance
• Low Impedance performance characteristics with High Impedance Compatibility
• Coil Resistance: 12 Ohms (This high-impedance injector will work with all factory ECM/PCM injector drivers)
• Gain:  0.75
• Spray Pattern:  Cone
• Electrical Connector:  USCAR / EV6 (New-style V=EV6 / Oval / LS2) – Adapters
• Fitted with Viton upper and lower O-rings
• Static Flow Rate @ 43.5 PSI (300 kPa): 44.5 lb./hr. = 5.86 g/s = 478 cc/min (+/-3%)
• Static Flow Rate @ 58.0 PSI (400 kPa): 51.7 lb./hr. = 6.77 g/s = 552 cc/min (+/-3%)
• Dynamic Flow Rate 2.5 ms PW @ 100 Hz (400 kPa):  11.42 mg/pulse +/-4%
• EV1 adapters can be purchased, so these injectors will fit EV1.

FI114357 (60mm)

Genuine Siemens DEKA High Impedance Injectors SET OF 8

These injectors flow 44.5 lbs,/hr. at 43.5 PSI (3 BAR) and much more at higher PSI!  In addition, these units are high-impedance.  Despite the high flow rate, they are linear and controllable at low pulse widths and have been used in ULEV applications!  This allows you to use a larger injector than normally possible without hurting idle and low-speed driveability.  Adding to the flexibility of application, these units are high-impedance, making them compatible with most ECUs, while delivering the most flow available in a High-Impedance injector.  These injectors represent the most current Siemens DEKA engineering and are used on much high power turbo and supercharged OEM applications.

These injectors are able to function at high fuel pressures and don’t exhibit the high fuel pressure handling problems found with many other high flow high-impedance injectors.  This makes these injectors very well suited to turbocharged and supercharged applications that see high fuel system pressures, and in fact, that is exactly what they were designed for!

Engine performance and running quality are enhanced through the optimized spray pattern.  Unlike competitors’ pencil stream high flow injectors, these High Flow injectors utilize a multi-orifice tip for improved mixture preparation and atomization.  This results in lower BSFC and better idle quality than many injectors with less flow.

Cross Reference:
Siemens FI114357

CPR RACING 44 lb./hr. Siemens Deka with EV6/USCAR Connector – FI114357

CPR 500060-44-8
